RPN - STATION INSTRUMENTATION

2. Global Seismograph Network - GSN:

DATES OF OPERATION:	08 Dec 1992 to 11 Feb 1994.

SEISMOMETER TYPE AND DATA ACQUISITION SYSTEM:
Streckeisen Model STS-1/VBB 3 component system for broadband, mid period and
very long period channels.  IDA MK6 data acquisition system.

CALIBRATION EPOCH:	1992, 343 - 1994, 042

DIGITAL FORMAT:
16 bit integer data words for all broadband (20 sps) and mid period (5 sps) data.
32 bit integer words for all very long period (0.1 sps) and synthesized long period
(1 sps) data.

Click on any of the following items for further information.
The Noise Study was done using 1993 data, consequently, it is only an estimation for this generation of station instrumentation.
