RAYN - STATION INFORMATION

2. Global Seismographic Network - GSN:

DATES OF OPERATION:	29 May 1996 to 01 Feb 1997.

SEISMOMETER TYPE AND ADC:
Streckeisen model STS-2 triaxial seismometer for broadband (40 sps), long
period and very long period channels. Streckeisen model STS-1/VBB. A three
component system for broadband, long period, and very long period channesl
recorded at 20, 1 and 0.1 sps respectively.  Kinemetrics FBA-23 three
component force balance accelerometer recorded at 1 sps continuous mode
and at 100 sps triggered mode.  IDA MK7 data acquisition system.

CALIBRATION EPOCH:	1996, 150 - 1997, 032

DIGITAL FORMAT:
32 bit integer data words for broadband (20 sps), long period (1 sps), very
long period (0.1 sps) and short period (40 sps) channels.  16 bit integer
data words for extremely short period (100 sps) triggered channels.
